Technical Specs

HxWxD (Nested):    8″ x 54″ x 22″ – 205 mm x 1,375 mm x 560 mm

HxWxD (Fully Upright):    55″ x 36″ x 22″ – 1,395 mm x 915 mm x 560 mm

Weight:    65 lbs – 30 kg

Power Requirements:   12V DC – 240w – 20 amps

                                      24V DC – 240w – 15 amps

Lighting:     (2) Whelen Pionner Plus PFH1B (LED) – 75w

                or (2) Whelen Pionner Plus PFH14 (LED) – 75w

Output (per light):    8,875 lumens

Total Watts:     150 watts

Total Output:    17,750 lumens
