FB24STHI and FB24STHI-024C-CN Fireball® Supervised Hearing Impaired Strobe Warning Light

[[POS2]]

Available in 24VDC
Four wires and supervisory diode
Clear dome
Easy twist off dome for re-lamping
Integrated 1/2-inch NPT pipe and surface mount
10,000 hour strobe tube
Black epoxy coating for superior corrosion resistance
In-rush protected
Conformal coated PCBA
Type 4X, IP66 enclosure
IP69K compliant
CSFM Approved
FB24STHI-024C is UL Fire Listed
FB24STHI-024C-CN is ULC Fire Listed

Voltage	24VDC
Material	1/2" Pipe
	Surface
Operating Current	0.7 Amps at 24VDC (2.0 Amps in-rush)
Dome Colors	Clear
Operating Temperature Minimum	-31 °F
Operating Temperature Maximum	150 °F
Light Source/Lamp Style	Strobe Tube
Flash Rate/Minute	80
Peak Candela	1,000,000
Effective Candela	300
Lamp Life	10,000 Hours
Enclosure Rating	Type 4X
Ingress Protection (IP)	IP66
Net Weight	1.45 lb
Shipping Weight	1.70 lb
Height	5.250 in
Diameter	4.100 in

Model FB24STHI features a voltage in-rush limiting PCB design that provides greater compatibility with control systems and panels and less electrical interference with in-rush sensitive devices.

Fireball FB24STHI contains a supervisory diode and four wire leads, for use in fire alarm applications. This strobe is UL Listed and ULC Fire Listed for hearing impaired applications.

PRODUCT LITERATURE

CS_FB24STHI_FB24STHI-0204C-CN_Rev0420

Replacement Lamps Reference Guide for Visual Signals

PRODUCT MANUALS

FB24STHI and FB24STHI-024C-CN Manual

AGENCY CERTIFICATES

UL Certificate of Compliance - FB24STHI and FB24STHI-024C-CN

CSFM Listed - FB24STHI

IP69K Test Report No. 1804450-01

IP69K Certified Models Declaration_0420

PRODUCT BROCHURE

Fire Alarm Notification Device Brochure_251

IP69K Brochure

IP69K Compliant Products Video (1:33)

ORDERING INFORMATION

Model Types

MODEL	DESCRIPTION	UPC
FB24STHI-024C	Strobe, 24VDC, 4-wire, hearing impaired, in-rush limited, clear	782979216551
FB24STHI-024C-CN	Strobe, 24VDC, 4-wire, hearing impaired, in-rush limited, ULC, clear	782979240808
